Technical Parameters:
| No. | Item | Details |
| 1 | W axis reducer | Alpha, Germany | Rated torque 167.3n.m,
Instaneous max. torque 585.2n.m,
Rated speed 43 rpm, max. speed 85 rpm |
| 2 | B axis reducer | Alpha, Germany | Rated torque 88.9n.m,
Instaneous max. torque 312n.m,
Rated speed 43 rpm, max. speed 85 rpm |
| 3 | C axis reducer | Alpha, Germany | Rated torque 88.9n.m,
Instaneous max. torque 312n.m,
Rated speed 43 rpm, max. speed 85 rpm |
| 4 | Z2 axis | Rexroth, Germany | Repeatability: +/-0.005mm |
| 5 | 8th axis second spindle | electric | 4.0kw, max. speed 26000 rpm,
6 additional tools
max. dia. of round cutter: 70mm
min. dia. of round cutter: 40mm |
| 6 | Transmission components | Rexroth, Germany | Repeatability: +/-0.005mm |
| 7 | Operation | SYNTEC system | 220MB-E5 inch screen operation box,
max. extending 600mm on width at left side |
| 8 | Servo motor | | 200w/400w/750w |
| 9 | Main spindle | electric | 3.7kw, max. speed 40000 rpm
water cooling with flow-alarm |
| 10 | Tool magazine | servo-drive | Up to 15 tools for vertical main spindle |
| 11 | Tool holder | | ISO20 |
| 12 | Collet chuck | | ER-16 |
| 13 | Lubrication | | Timing automatic oiling |
| 14 | Working flatness | | +/-0.005mm |
| 15 | X1 axis stroke | | 380mm |
| 16 | X2 axis stroke | | 80mm |
| 17 | Y axis stroke | | 50mm |
| 18 | Z1 axis stroke | | 90mm |
| 19 | Body weight | | 1.7 tons |
| 20 | Front door | | sliding door |
| 21 | Layout (mm) | main body | 1600 width*1300 depth*2050 height |
| 22 | Power requirement | three-phase | 380v/50hz |
Support and Services:
Technical support
Installation
Training
Maintenance
Troubleshooting
Software upgrade
Packing and Shipping:
Fumigation wooden case by sea or by air
FAQ:
Q: Are you a dealer or manufacturer?
A: We, Guanglijin, is a manufacturer of CAD/CAM CNC machine with over 20 years experience.
Q: Where are you from?
A: We are from Shenzhen China, one of the most creative city in the world.
Q: Do you provide overseas support or service?
A: Yes, we have a technican team which can travel abroad to do global service and support.
Q: Does this machine come with any certification?
A: Our machines are CE certificated.
